Product Introduction
Dust control in woodworking shops, grinding rooms and light processing plants depends on the 4-72 3.6A 3KW Dust Collecting Fan to carry chips, shavings and fine dust from hoods to collectors. The fan is driven by a 3KW-2P motor supplied from three-phase 380V 50Hz mains, spins at 2870r/min and moves an air flow of 2664-5268m³/h while building a total pressure of 1578-989pa that overcomes duct and filter resistance. Motor frame 100 and 206 front and rear motor bearings give this dust fan solid support for dusty conditions. Compact enough for small collector stations, the 4-72 3.6A 3KW Dust Collecting Fan measures 585x715x595mm overall and weighs 48.9kg (51.2kg for the heat-insulated type), traveling in a woven bag. To keep your workshop air breathable, hook the 4-72 3.6A 3KW Dust Collecting Fan to your dust-collection ductwork and let it do the pulling.
Product Parameter
| Specification | Details |
|---|---|
| Model | 4-72 3.6A |
| Power Supply | Three-phase 380V 50Hz |
| Power | 3KW-2P |
| Speed | 2870r/min (2-pole) |
| Air Flow | 2664-5268m³/h |
| Total Pressure | 1578-989pa |
| Motor Frame | 100 |
| Motor Bearings | Front 206, Rear 206 |
| Fan Weight | 48.9kg |
| Fan Weight | 51.2kg (heat-insulated type) |
| Overall Dimensions | 585715595mm |
| Packaging | Woven bag |
