Product Introduction
Where a dust collector or a conveying loop needs extra headroom, the 2.2KW DF-2.5-II High Pressure Blower Fan shifts 3300 to 4000 m3/h of air while holding 1470 to 1300 pa of total pressure at 2800 r/min. The two-pole motor is mounted on frame 90L, and front and rear bearings 205 keep vibration low during round-the-clock operation. Supply can be three-phase 380V 50Hz or single-phase 220V 50Hz, and the single-phase machine uses a 60uF running capacitor to start and run smoothly. Three-phase fans weigh 24 kg while single-phase fans weigh 35 kg, both fitting within an overall envelope of 445 x 385 x 450, and every unit is packed in a wooden case for export shipping. Operators moving wood dust, granules or light trim waste benefit from the steady pressure curve of the 2.2KW DF-2.5-II High Pressure Blower Fan as filter media gradually loads up. Because the motor and fan body share one compact assembly, mounting onto a filter stand or a machine frame is straightforward. If the process demands heavy airflow with firm static pressure and quiet two-pole operation, select the 2.2KW DF-2.5-II High Pressure Blower Fan for the job.
Product Parameter
| Specification | Details |
|---|---|
| Model | DF-2.5-II |
| Power | 2.2KW |
| Air Flow | 3300-4000m³/h |
| Total Pressure | 1470-1300pa |
| Speed | 2800r/min (2-pole) |
| Power Supply | Three-phase 380V 50Hz / Single-phase 220V 50Hz |
| Motor Frame | 90L |
| Running Capacitor | 60μF (single-phase) |
| Motor Bearings | Front 205, Rear 205 |
| Fan Weight | 24kg (three-phase), 35kg (single-phase) |
| Overall Dimensions | 445385450 |
| Packaging | Wooden case |
